Technical Data:

• Operation Weight: 1 Ton


• Engine: Kubota Diesel Engine


• Equipped with Air Conditioned Enclosed Cabin


• Equipped with Side Swing

Engine:

• Brand: Kubota


• Model: D722


• Type: 3-cylinder diesel engine


• Power Output: 10.2 kW


• Maximum Speed: 3,600 RPM


• Emissions Compliance: Tier 4

Performance:

• Operating Weight: 980 kg (2,160 lbs)


• Maximum Digging Depth: 1,693 mm (66.7 inches)


• Maximum Digging Height: 2,560 mm (100.8 inches)


• Maximum Loading Height: 1,800 mm (70.9 inches)


• Minimum Rotation Radius: 3,060 mm (120.5 inches)


• Travel Speed: 0-1.8 km/h


• Climbing Ability: 15°

Dimensions:

• Overall Length: 2,925 mm (115.2 inches)


• Overall Width: 958 mm (37.7 inches)


• Overall Height: 2,422 mm (95.4 inches)

Hydraulic System:

• Main Pump Type: GP510803


• Rated Set Pressure: 25 MPa


• Maximum Flow Rate: 21.6 L/min


• Multi-Circuit Valve: 4 mechanical + 4 hydraulic


• Rotary Hydraulic Motor Type: BM2-315


• Traveling Hydraulic Motor Type: BM6-315

Additional Features:

• Cabin: Enclosed with air conditioning


• Side Swing: 30° angle


• Bucket Capacity: 0.03 m³
